Nominal power |
W |
1600 |
Output power |
W |
1100 |
Rated speed |
1/min |
430 |
Total length |
mm |
360 |
Weight without cable |
kg |
5.4 |
hand-held |
mm |
100-250 |
Tool fixture |
1-1/4”UNC |
|
Mounting neck Ø |
mm |
60 |
Remarks |
Dry |
Advantages:
* Virtually
dust-free drilling of holes for installation sockets. Adapting sleeve for the
dust exhausting can be moved 300° radially.
* Extended handle
to hold the high torque for hand-held drilling of holes in masonry up to 250 mm.
* Levelling
assistance – by two integrated levels.
* Motor protection
and soft start by means of the Intellitronic.
* Gear box with oil
bath lubrication and overload clutch.
* Tough and
reliable design as a result of the full metal housing, compact design.
* Springy centering
spike for a safe and precise start of drilling as accessory.
* Supplied with a
complete tool set in a practical suitcase.
Applications:
* Creating big
drill holes in masonry, especially in chimney brick and ceramic tubes.
