Nominal power |
W |
2000 |
Output power |
W |
1340 |
Rated speed |
1/min |
540/1200/2520 |
Total length |
mm |
420 |
Weight without cable |
kg |
6.3 |
Drilling Ø concrete c.rig operated |
20-160 |
|
hand-held |
mm |
20-100 |
Tool fixture |
1-1/4”+G1/2” |
|
Mounting neck Ø |
mm |
60 |
Remarks |
Wet+Dry |
Advantages
* Wet and dry
drilling in different materials without any involved changing of the
accessories or attachments.
* High-performance,
air-cooled motor with a wide drilling range.
* 3-speed-gear with
oil bath lubrication and overload clutch.
* Motor protection
and soft start by means of the Intellitronic.
* Especially developed
sealing system for wet and dry drilling.
* Levelling
assistance – by two integrated levels.
* Tough and
reliable design as a result of the full metal housing, compact design.
* Antifriction-Element
for easy loosening of the drill bit.
* Tool adapter for
G 1/2″ bits and vacuum-adapter are included.
* Supplied with a
complete tool set in a practical suitcase.
* Springy centering
spike for a safe and precise start of drilling as accessory.
Applications:
* Wet and dry
drilling of through-holes in concrete, masonry and stone for cables, cable
trays and pipes.
* Wet and dry
drilling in ceilings, floors and walls.
* Stitch drilling
of through-holes in plumbing, and air conditioning installations.
* Ventilation
openings.
