Rated Voltage |
V |
230 |
Rated current |
A |
16 |
Nominal power |
W |
3700 |
Output power |
W |
2700 |
Rated speed |
1/min |
230/570 |
Total length |
mm |
440 |
Weight without cable |
kg |
14.7 |
Drilling Ø concrete c. |
mm |
80-370 |
Tool fixture |
1-1/4”UNC |
|
Foot fastening |
Standard 4 x M8 with groove 10 x 4,3 |
Advantages:
* Very powerful,
water cooled SR-motor; low in maintenance, due to no carbon brushes and turning
windings.
* High performance
– compact design, low weight.
* Six finely
matched steps for a perfect adjustment of the revolution speed.
* Gear with oil
bath lubrication, oil pump and high-duty overload clutch.
* Splash water
proof according IP 55, ready for drilling overhead without any further
precautions.
* Simple to use
keypad and display, showing drilling diameter and error analysis.
* Soft turn –
screwing speed for easy assembling of the bit.
Applications:
* Wet drilling in
ceilings, floors and walls.
* Through-holes for
cables, cable trays and pipes.
* Corner holes for
sawing.
* Ventilation openings.
